2027 Big Tex Trailers 102″X25’+5′ DECKOVER GOOSENECK 22GN Equipment Trailer
2027 Big Tex Trailers 102″X25’+5′ DECKOVER GOOSENECK 22GN Equipment Trailer. Equipment Trailer by Big Tex Trailers. Available colors: BLACK. Condition: New.
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
2027 Big Tex Trailers 102″X25’+5′ DECKOVER GOOSENECK 22GN Equipment Trailer from Big Tex Trailers. Explore model specifications and the available equipment shown in the product gallery. Condition: New.
2027 Big Tex 22GN 25+5 Deckover Gooseneck Trailer
Explore this Big Tex 22GN with a listed 102-inch width and 25+5-foot deck. Although it shares a model family with longer 22GN trailers, the usable deck length is different. Match your load dimensions, ramps, gross trailer rating and allowed payload to this exact configuration.
Before Towing
Check gooseneck truck and hitch compatibility, tires, axles, brakes, securement points and included equipment. Confirm trailer empty weight and the remaining weight available for cargo, and follow manufacturer-approved loading procedures.
Compare equipment trailers, view DLR inventory or ask about this Big Tex unit.
25+5-Foot Deck Loading Guide
Measure your equipment at its widest and longest points, accounting for buckets, attachments and guards. The manufacturer’s deck sections and usable ramp angle should be checked before trying to load a machine. Gross weight rating includes the trailer itself; subtract verified empty weight to determine available cargo payload.
Questions Before Ordering
- Confirm this exact 22GN 25+5-foot model instead of the longer 35+5 listing.
- Review trailer GVWR, axles, brakes, tires and actual payload.
- Check truck and gooseneck hitch ratings for the loaded combination.
- Confirm ramp arrangement and securement points.
- Verify additional equipment or accessories included with the unit.
Product Specifications
| Condition | New |
|---|---|
| Color | BLACK |
| Model Name | 102"X25'+5' DECKOVER GOOSENECK 22GN |
| Model Year | 2027 |
| Model Number | 22GN-30D5A-MRBK |
| Axles | 2 x 10000 lb Dual Wheel with Electric Brakes and Oil Bath Hubs |
| Coupler | 2-5/16 inch Demco EZ Latch Adjustable Gooseneck Coupler |
| Deck Length | 25 foot flat deck plus 5 foot dovetail with spring-assist ramps |
| Frame | 12 inch x 19 lb Low-Profile Pierced I-Beam Frame with TwistGuard Design |
| GVWR | 23900 |
| Jacks | Dual 12000 lb Drop-Leg Jacks with Bolt-On Design |
| Length | 30ft0in |
| Pull Type | Gooseneck |
| Suspension | Heavy-Duty 30000 lb Adjustable Suspension |
| Warranty Forever | 1 |
| Weight | 7460 |
| Width | 0ft102in |
Photos may show different units or equipment configurations. Contact DLR Golf Carts to confirm the specific item and availability.
| Weight | 7460 lbs |
|---|---|
| Dimensions | 360 × 102 in |
| Condition | New |
| color | Black |
| Brand | Big Tex Trailers |
| Model Name | 102"X25'+5' DECKOVER GOOSENECK 22GN |
| Model Year | 2027 |
| Equipment Category | Equipment Trailer |
| Model Number | 22GN-30D5A-MRBK |
| Axles | 2 x 10000 lb Dual Wheel with Electric Brakes and Oil Bath Hubs |
| Coupler | 2-5/16 inch Demco EZ Latch Adjustable Gooseneck Coupler |
| Deck Length | 25 foot flat deck plus 5 foot dovetail with spring-assist ramps |
| Frame | 12 inch x 19 lb Low-Profile Pierced I-Beam Frame with TwistGuard Design |
| GVWR | 23900 |
| Jacks | Dual 12000 lb Drop-Leg Jacks with Bolt-On Design |
| Length | 30ft0in |
| Pull Type | Gooseneck |
| Suspension | Heavy-Duty 30000 lb Adjustable Suspension |
| Warranty Forever | 1 |
| weight | 7460 |
| Width | 0ft102in |
